Product features

• ? 7 inch color touch screen;

• ? Support multi language, convenient for different users;

• ? Built in environment automatic detection program, automatically detect the test environment and remind users;

• ? Built in international standard grade parameters, easy and fast operation;

• ? Built in voltage and current probes, convenient for users to detect the output waveform;

• ? Self calibration function to ensure the normal operation of the equipment;

• ? RS232 interface, optional PC control software operation.

Product parameters

• Product model:


  Surge waveform


  Open circuit voltage


  short-circuit current


  Surge polarity


  Phase angle


  Programmable test program


  Output impedance


  Coupling / decoupling network


  Surge coupling mode


  frequency


  Interval time


  Working power supply


  ambient temperature

• SUR S8


  Voltage wave: 1.2/50 main 20%us current wave: 8/20 main 20%us


  0.2~8kv main 5%


  0.1~4kA±5%


  Positive, negative, positive / negative, negative / positive, alternating positive and negative,


  0~360 ° synchronous or asynchronous make-up 1 °


  Built in IEC standard, user-defined, programming, up to 40 groups


  2q (common mode 12q2)


  Built in, single-phase three wire, 16a, 50hz/60hz


  Differential mode 18uf/2q, common mode 9uf /10q


  1 ~ 9999 times


  10~9999s


  AC220V±10%; 50/60Hz 150W


  Temperature: 15 ℃ ~35 ° ℃; Relative humidity 10%-70%
